ALLNET ISP Bridge Modem g.fast mit Supervectoring / Punkt-zu-Punkt Modem VDSL g.fast via 2-Draht managed Slave ALL-BM300

ALLNET ISP Bridge Modem g.fast mit Supervectoring / Punkt-zu-Punkt Modem VDSL g.fast via 2-Draht managed Slave ALL-BM300 Highlight: Universelles VDSL2 Features: Compliant with IEEE 802.3 / 802.3u / 802.3ab Ethernet Standard Compliant with ITU-T G993.2 VDSL2 standard (ALL-BM300 only) Compliant with ITU-T G998.4 G.INP standard (ALL-BM300 only) Compliant with ITU-T G.9700/G.9701 G.fast standard Backward compatible VDSL2/V35b (ALL-BM300 only) Support 106a/ < 212a/ dual G.fast band profile Support super Vectoring for V35b / G.fas(ALL-BM300 only) Support Vectoring for VDSL2(ALL-BM300 only) Support High Bandwidth up to 1Gbps Support USB 3.0 for connecting USB Dongle Support static routing for IPv4 and IPv6 forwarding(ALL-BM300 only) Mac Address based filtering Support 8 queue MFC/DSCP both type QoS Support HTTP/HTTPS web management Support SSL security Support remote management and monitor Support configuration backup and restore On board surge protection for Line port Support bridge(switch) / Router mode(ALL-BM310 Master only) Support RJ-11 / Terminal block combo line port Support NTP Time Server. Support TR-069. On board POTS/ISDN splitter Support Jumbo frame(MTU) up to 1600 bytes  Specifications   Standards IEEE802.3/802.3u/802.3ab standards ITU-T G9700/G9701 standards ITU-T G993.2/G998.4 standards (ALL-BM300 only) Physical Interface 4 x RJ-45 10/100/1000 Mbps Ethernet port 1 x RJ-11 / Terminal block combo for line port 1 x RJ-11 connector for POTS/ISDN phone device 1 x Reset Button for resetting to factory default 2 x USB3.0 for connecting USB dongle Button 1 x Power LED 4 x Link/Active Status for Ethernet port 1 x Link LED for G.fast mode 1 x Link LED for xDSL mode  Routing
(ALL-BM300 only)  IP Multicast, IGMP Proxy, Snooping
Static Routing IPv4, IPv6 forwarding
DHCP Server/Relay/Client IPv4/IPv6
DNS Proxy and Relay, NTP Client Firewall  IPv6 Firewall
Packet, URL filtering
Parental Control, DMZ Host Input Power DC 12V / 2A including Dimensions:  196mm x 146mm x 40 mm ( 19,6 cm ( 7,7 Zoll ) x 14,6 cm ( 5,8 Zoll ) x 1.57”) Net weight: approx. 0.4 kg Temperature 0°~50° C (Operating), -20° ~70° C (Storage) Humidity  10 - 90% non-condensing Marks CE FCC RoHS Compliant Package Contents: 1x ALL-BM300 1x 12V/2A Powersupply 1x Patchcale 1x QIG
