Aten US221A USB-Switch 2-fach

Aten USB-Switch 2-fach,

*Auftragsbezogene Bestellung *

PC1-2: je(USB B Buchse)

Device Side: USB A Buchse

US221





+ Download :





2-Port USB 2.0 Peripheral Switch



US221 allows 2 computers to share the same USB peripheral under the foundation of one-at-a-time. Users can switch the computer controlling the peripheral from the simple hotkeys or buttons on the front panel or the control software on Windows. It is ideal for SOHO environments.





Features





Enables two computers to share a single USB peripheral device.

Hotkey, front panel pushbutton and Windows AP for simple port selection.

USB 2.0 compatible.

Supports transfer rates of 1.5/12/480 Mbps.

Overcurrent protection.

Bus powered.

LED indicators display port focus.

Beep indicates PC change and busy status.

Hot pluggable - USB devices can be attached and removedwithout resetting the system.

Plug and play.

OS Support:Windows 2000, Windows XP, Windows Vista, Mac and FreeBSD





Package Content





1x USB Peripheral Switch

1x USB Cable

1x Driver Disk

1x User Manual





Diagram





+ View enlargement





Specification





Console Connection 2

PC Selection Hotkey, Pushbuttons, AP*

Connectors Computer Side 2 x USB Type B Female

Device Side 1 x USB Type A Female

LEDs Devices 1 (Orange)

Selected 2 (Green)

Switches 1 x Pushbutton

Power Supply Bus powered

Environment Operating Temperature 5°~40°C

Storage Temperature -20°~60°C

Humidity 0~80% RH, NC

Physical Properties Housing Plastic

Weight 55 g

Dimensions ( L x W x H ) 7.19 x 6.59 x 2.5cm

* Hotkeys and the AP program only operate on the windows OS, Mac users must use the pushbutton to switch ports.





* The specification and pictures are subject to change without notice.

* All trademarks and logos are the properties of their respective holders.
