MikroTik RB912UAG-5HPnD Routerboard

MikroTiK Routerboard RB912UAG-5HPnD

RouterBOARD 912UAG with 600Mhz Atheros CPU, 64MB RAM, 1xGigabit LAN, USB, miniPCIe, built-in 5Ghz 802.11a/n 2x2 two, chain wireless, 2xMMCX connectors, RouterOS L4



RB911G-5HPacD



RouterBOARD 911G-5HPacD is our low-cost small form factor CPE board with 802.11ac support. It’s perfect for building low-cost 802.11ac CPE devices, as the list price is only $79. Yet, the device is very powerful- it’s equipped with 720MHz CPU, 128MB RAM, Gigabit Ethernet port, power jack and 1300mW 802.11ac 5GHz Dual Chain wireless onboard. Comes with RouterOS L3 license.

Product specifications

Details

Product code RB911G-5HPacD

CPU nominal frequency 720 MHz

CPU core count 1

Size of RAM 128 MB

10/100 Ethernet ports None

10/100/1000 Ethernet ports 1

MiniPCI slots 0

MiniPCI-e slots 0

Wireless chip model QCA9882-BR4A-R

Wireless standards 802.11ac

Number of USB ports 0

Power Jack 1

Supported input voltage 8 V - 30 V

PoE in Yes

PoE out No

Voltage Monitor Yes

CPU temperature monitor No

PCB temperature monitor Yes

Dimensions 105x105mm

Operating System RouterOS

License level 3

Antenna gain DBI No

Current Monitor No

CPU QCA9557-AT4A-R

Max Power consumption 12 W

SFP ports None

SFP+ ports None

Number of chains 2

Serial port None

Suggested price $79.00
